Fiber Optic Cables: MIC Tight-Buffered, Interlocking Armored Cable, Plenum, 24 Fiber, 50 Multimode (OM4) (024T88-33190-A3)

Corning

SKU:
024T88-33190-A3

Call 888-681-1768 for Price and Lead Time

Minimum Purchase:
1 ft

Call 888-681-1768 for Price and Lead Time

Description

At ProWireandCable.com, our great variety of high-quality fiber optic cables includes the MIC Tight-Buffered, Interlocking Armored Cable, Plenum, 24 Fiber, 50 Multimode (OM4) (024T88-33190-A3)!

Description

Corning Cable Systems MIC Interlocking Armored Plenum Cables are designed for use in plenum, riser and general purpose environments for intrabuilding backbone and horizontal installations. These multifiber cables use individually jacketed TBII Buffered Fibers enabling easy, consistent stripping and facilitating termination. The fibers are grouped into jacketed subunits and surrounded by a dielectric central member.

The core is protected by a flexible, spirally wrapped, aluminum interlocking armor that offers easy, one-step installation and over seven times the crush protection of unarmored cables. With a flame-retardant outer jacket, this cable is particularly useful for heavy traffic or more challenging mechanical exposure conditions and applications requiring extra rugged cables.

This cable is available in 12 different jacket colors - blue, orange, green, brown, slate, white, red, black, yellow, purple, rose and aqua. The colored jacket allows for easy visual identification of the cables.

Applications

General Purpose Horizontal, Vertical Riser, Plenum

Specification Description

  • Cable Type: Tight-Buffered
  • Environment: Indoor
  • Fiber Category: 50 µm MM (OM4)
  • Flame Rating: Plenum (OFCP)
  • Product Type: Interlocking armor
  • Central Element: Yarn
  • Fiber Count (cable): 24
  • Inner Jacket Material: Flame-retardant
  • Number of Ripcords: 2
  • Outer Jacket Color: Aqua
  • Outer Jacket Material: Flame-retardant
  • Tensile Strength Elements and/or Armoring - Layer 1: Dielectric strength members
  • Tensile Strength Elements and/or Armoring - Layer 2: Dielectric strength members
  • Tensile Strength Elements and/or Armoring - Layer 3: Interlocking armor
  • Tight Buffer Color, Layer 2: Violet, Rose, Aqua, Blue*, Orange*, Green*, Brown*, Slate*, White*, Red*, Black*, Yellow*, Violet*, Rose*, Aqua*
  • Tight Buffer Color: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow
  • Max. Tensile Strengths, Long-Term (Metric): 200 N
  • Max. Tensile Strengths, Long-Term (US): 45 lbf
  • Max. Tensile Strengths, Short-Term (Metric): 660 N
  • Max. Tensile Strengths, Short-Term (US): 150 lbf
  • Min. Bend Radius Installation (Metric): 215 mm
  • Min. Bend Radius Installation (US): 8.5 in
  • Min. Bend Radius Operation (Metric): 143 mm
  • Min. Bend Radius Operation (US): 5.6 in
  • Nominal Inner Cable Diameter (Metric): 7.8 mm
  • Nominal Inner Cable Diameter (US): 0.31 in
  • Nominal Outer Diameter (Metric-mm): 14.3 mm
  • Nominal Outer Diameter (US): 0.56 in
  • Weight (cable) (Metric): 197 kg/km
  • Weight (cable) (US): 136 lb/1000 ft
  • Temperature - Installation (Metric): 0 C to 60 C
  • Temperature - Installation (US): 32 F to 140 F
  • Temperature - Operation (Metric): 0 C to 70 C
  • Temperature - Operation (US): 32 F to 158 F
  • Temperature - Storage (Metric): -40 C to 70 C
  • Temperature - Storage (US): -40 F to 158 F

Tech Info

Approval and Listings: National Electrical Code (NEC) OFCP, CSA FT-6, ICEA S-83-596; Flame Resistance: NFPA 262 (for plenum, riser and general building applications)

For more items, we ask you to spend some time to look at our whole variety of fiber optic cables at ProWireandCable.com now.

Specifications

Brand:
Corning
Armored:
YES
Fiber Type:
OM4 LAZER-OPTIMIZED 50 MICRON, 10 GIG TO 550 METER
Max Tensile Load (Installation) lb.:
150
Max Tensile Load (Long Term) lb.:
45
Manufacturer:
Corning
Manufacturers item number:
024T88-33190-A3
Min Bend Radius (Install) in.:
8.5
Min Bend Radius (Long Term) in.:
5.6
Number of Fibers:
24
Outside Diameter:
0.56
Plenum/Riser:
PLENUM
Type:
TIGHT BUFFERED
Weight per Foot:
0.17

Manufacturer Equivalents

Anixter item:
370-COROM4-TBA-24
Corning Item:
024T88-33190-A3
Wirexpress item:
024T88-33190-A3
